Basic Info.
Model NO.
CHEMSHUN CERAMICS
Material
Alumina Ceramics
Feature
Wear Resistant
Corrosion Rate
0
Item
Alumina Ceramic Groovy Tile
Materials
Alumina Ceramic
Alumina Content
92% Al2O3
Size
150*100*6~50mm, 100*100*6~30mm
Shape
Plain,Weldable,Cylinder,Hexagon,Curved
Advantage
Reduce Downtime,Maintainace Cost,Repair Cost
Indusry
Coal,Power Generation,Steel,Cement
Types
Scraper Tiles, Screens, Wedges, Guides, Mechanica
Fields
Chutes, Hoppers, Silos Feeders, Mixers, Centrifug
Usage
as Wear Ceramic Lining in Wear Protection
Transport Package
Paper Carton + Pallet
Specification
150*50*6~25mm; 100*100*6~30mm; 120*80*6~30mm
Trademark
Chemshun
Origin
China
HS Code
69091200
Production Capacity
5000 Tons /Year
Product Description
92% Alumina Interlocking Ceramic Tile as Wear Resistant Materials
Product Description
The goovy alumina tiles can be shaped in plain,weldable,interlocking and curved shaped. It was used as the wear resistant ceramic material for the steel equipment. The installation way can be bonding directly or welding accordingly to different application.
Pingxiang Chemshun Ceramics Co.,Ltd is a leader in developing and manufacturing of the wear resistant alumina ceramic lining tiles since 2002.Our product range is including the follows:
-Wear resistant alumina ceramic liner/cylinder/mosaic/hexagon tile/ceramic cubes.
-Abrasion resistant Alumina ceramic pipe/tubes ,diameter from 20mm to 500mm
-Ceramic rubber wear liner/Steel Rubber ceramic composite panel.
-Wear resistant pre-engineering ceramic tile in a variety of geometric shapes from simple to complex,the ceramics can be engineered or moulded to specific shapes to customer's requirement.
-Ceramic lined equipment like pipes,bends,chutes,hoppers,bunkers, etc.
Alumina ceramic liner has excellent abrasion resistance,hard resistant,corrosion resistance,it is widely used in the mining,power plant,steel plant,cement industries like chutes,hooper,bunker,cyclone,convey beltetc. This alumina ceramic product make cost effective performance like reduce unessesary down time and maintance,and prolong the equipment from quick abrasion.
With 13 year's experience in the wear protection field,Chemshun is not only a manufacturer but also an wear solution provider.It has the technician team who can help the client to choose the right product,also it can design the layout drawing and installation of ceramics for the clients.Also we are designing new products to meet the market.
Feature
· Excellent corrosion resistance property
· Easily handled size and weight
· Excellent heat resistance property
· Excellent impact resistance property
· Fast and safe installation
· Lower production and maintenance cost
Chemshun Ceramic Advantages
· Professional technical team to afford CAD designs
· Professional installation team to afford install service
· Well established process as per international standards
· Accept the standard and pre-engineered tiles
Dimensions
Application in Industries
Technical Data Sheet
Product Description
The goovy alumina tiles can be shaped in plain,weldable,interlocking and curved shaped. It was used as the wear resistant ceramic material for the steel equipment. The installation way can be bonding directly or welding accordingly to different application.
Pingxiang Chemshun Ceramics Co.,Ltd is a leader in developing and manufacturing of the wear resistant alumina ceramic lining tiles since 2002.Our product range is including the follows:
-Wear resistant alumina ceramic liner/cylinder/mosaic/hexagon tile/ceramic cubes.
-Abrasion resistant Alumina ceramic pipe/tubes ,diameter from 20mm to 500mm
-Ceramic rubber wear liner/Steel Rubber ceramic composite panel.
-Wear resistant pre-engineering ceramic tile in a variety of geometric shapes from simple to complex,the ceramics can be engineered or moulded to specific shapes to customer's requirement.
-Ceramic lined equipment like pipes,bends,chutes,hoppers,bunkers, etc.
Alumina ceramic liner has excellent abrasion resistance,hard resistant,corrosion resistance,it is widely used in the mining,power plant,steel plant,cement industries like chutes,hooper,bunker,cyclone,convey beltetc. This alumina ceramic product make cost effective performance like reduce unessesary down time and maintance,and prolong the equipment from quick abrasion.
With 13 year's experience in the wear protection field,Chemshun is not only a manufacturer but also an wear solution provider.It has the technician team who can help the client to choose the right product,also it can design the layout drawing and installation of ceramics for the clients.Also we are designing new products to meet the market.
Feature
· Excellent corrosion resistance property
· Easily handled size and weight
· Excellent heat resistance property
· Excellent impact resistance property
· Fast and safe installation
· Lower production and maintenance cost
Chemshun Ceramic Advantages
· Professional technical team to afford CAD designs
· Professional installation team to afford install service
· Well established process as per international standards
· Accept the standard and pre-engineered tiles
Dimensions
| ITEM NO. | PRODUCT | LENGTH x WIDTH | THICKNESS | Q'TY PER BOX |
| mm | mm | pcs | ||
| 1 | PLAIN TILE | 100 x 100 | 6 | 50 |
| 2 | PLAIN TILE | 100 x 100 | 12 | 20 |
| 3 | PLAIN TILE | 100 x 100 | 15 | 15 |
| 4 | PLAIN TILE | 100 x 100 | 25 | 10 |
| 5 | PLAIN TILE | 100 x 100 | 50 | 5 |
| 6 | PLAIN TILE | 100 x 25 | 6 | 135 |
| 7 | PLAIN TILE | 150 x 100 | 6 | 50 |
| 8 | PLAIN TILE | 150 x 100 | 12 | 20 |
| 9 | PLAIN TILE | 150 x 100 | 15 | 15 |
| 10 | PLAIN TILE | 150 x 100 | 25 | 10 |
| 11 | PLAIN TILE | 150 x 100 | 50 | 5 |
| 12 | PLAIN TILE | 150 x 50 | 12 | 40 |
| 13 | PLAIN TILE | 150 x 50 | 25 | 20 |
| 14 | PLAIN TILE | 150 x 25 | 6 | 135 |
Application in Industries
| Industry | Equipment system | Equipment parts |
| Cement | Pre-blending system for crashing limestone and crude fuel | Chute, bunker, pulley lagging, discharge cone |
| Raw mill system | Feed chute, retaining ring, scraper plate, seal ring, pipeline, bucket guard, cyclone, powder concentrator body, bunker | |
| Cement mill system | Chute, bunker, fan vane wheel, fan casing, cyclone, circular duct, conveyer | |
| Ball mill system | Pulverizer exhauster's body and vane wheel, powder concentrator's body, pulverized coal's pipeline, hot air duct | |
| Sintering system | Inlet/outlet bend, wind value plate, cyclone, chute, dust collector's pipe | |
| Afterheat system | Separator's pipeline and wall | |
| Steel | Raw material feeding system | Hopper, silo |
| Batching system | Mixing bunker, mixing barrel, mixing disk, disk pelletizer | |
| Sintered material transport system | Hopper, silo | |
| Dedusting and Ash discharge system | Dedusting pipeline, bend, y-piece | |
| Coking system | Coke hopper | |
| Medium-speed mill | Cone, separation buffles, outlet pipe, pulverized coal's pipeline, burner cone | |
| Ball mill | Classifier, cyclone separator, bend, powder concentrator's inner shell | |
| Thermal power | Coal handling system | Bucket wheel machine, coal hopper, coal feeder, orifice |
| Ball mill system | Separator's pipe, elbow and cone, coal mill's elbow and straight tube | |
| Medium-speed mill | coal mill body, separation buffles, cone, pipeline, elbow | |
| Fall mill | Pulverized coal's pipeline and elbow | |
| Dedusting system | Dedusting's pipeline and elbow | |
| Ash discharge system | Fan duster's shell, pipeline | |
| Port | Transporting material system | Bucket wheel machine's disk and hopper, transfer point's hopper, unloader's hopper, |
| Smelting | Transporting material system | Measuring hopper, coke hopper, vibrating screen's chute, head valve, Intermediate bin, tail bin |
| Batching system | batch hopper, mixing machine | |
| Burning system | Ash bucket, pump calcine tube, hopper | |
| Dedusting system | Dedusting's pipeline and elbow | |
| Chemical | Transporting material system | Hopper, silo |
| Dedusting system | Dedusting's pipeline and elbow | |
| Processing equipment | Vibromill liner | |
| Coal | Coal handling system | Bucket wheel machine, coal hopper, coal feeder |
| Coal washing system | Hydrocyclone | |
| Mining | Transporting material system | Hopper, silo |
Technical Data Sheet
| S.No. | Attributes | Unit | CHEMSHUN 92 I | CHEMSHUN92 II |
| 1 | Alumina Content | % | 92 | 92 |
| 2 | Density | g/cc | ≥3.60 | ≥3.60 |
| 3 | Color | - | White | White |
| 4 | Water Absorption | % | <0.01 | <0.01 |
| 5 | Flexural Strength | Mpa | 270 | 300 |
| 6 | Moh's Density | Grade | 9 | 9 |
| 7 | Rock Well Hardness | HRA | 80 | 85 |
| 8 | Vickers Hardness(HV5) | Kg/mm2 | 1000 | 1150 |
| 9 | Fracture Toughness (Min) | MPa.m1/2 | 3-4 | 3-4 |
| 10 | Compressive strength | Mpa | 850 | 850 |
| 11 | Thermal Expansion Coefficient (25-1000ºC) | 1x10-6/ºC | 8 | 7.6 |
| 12 | Maximum operation temperature | ºC | 1450 | 1450 |
