Basic Info.
Model NO.
Chemshun ceramics
Place of Origin
Pingxiang Chemshun Plant,China
Materials
Alumina Ceramics
Alumina Content
92%,95%
Density
>=3.60g/cm3
Appearance
Square Tiles with Chamfer, Water Polished, Smooth
Use for
as Wear Resistance Part for Protection Equipments
Application Method
Rubber Backed /Lining/Vulcanized Ceramic
Application Equipment
Hopper, Chute, Conveyer, Bunker, Concrete Storage
Sample & Store
Available
Export Markets
Global
Acid Resistance
Yes
Impact Resistance
Yes
Abrasion Resistance
Yes
Anti-Corrosion
Yes
OEM, ODM
Accept
Transport Package
Paper Carton + Pallet
Specification
S17.5xT4-15mm, S20xT2-16mm
Trademark
CHEMSHUN
Origin
Pingxiang, China
HS Code
69091200
Production Capacity
5000 Ton/ Year
Product Description
Alumina Oxide Ceramic Block for Rubber Vulcanization
Product Description
Alumina ceramic plain tile
High aluminum Al2O3 high density ceramic tiles
Ceramic wear plates
Chemshun Alumina Ceramic Block cube is designed as per the customers' engineering requirements combined with the cost, installation and effective of application. Especially the blocks with tongues and grooves, Its obvious performance is that they could lock each other due to the tongues and grooves to increase the connectivity in whole engineering. So it is used widely in pipe lining, ceramic rubber plate etc.
Appearance
Character
-- Special Shape with grooves or tongues
-- Designed for special engineering
-- Excellent connectivity
-- Easy to pack and installation for using
Size
Advantages
--- Tailor made engineered ceramics available
----Accept OEM & ODM wear engineered ceramics and project
--- Provide professional industrial wear consult and solution
---- Accept small and big quantity order
---- Delivery fast
Physical Perfomance
Product Description
Alumina ceramic plain tile
High aluminum Al2O3 high density ceramic tiles
Ceramic wear plates
Chemshun Alumina Ceramic Block cube is designed as per the customers' engineering requirements combined with the cost, installation and effective of application. Especially the blocks with tongues and grooves, Its obvious performance is that they could lock each other due to the tongues and grooves to increase the connectivity in whole engineering. So it is used widely in pipe lining, ceramic rubber plate etc.
Appearance
Character
-- Special Shape with grooves or tongues
-- Designed for special engineering
-- Excellent connectivity
-- Easy to pack and installation for using
Size
| Alumina ceramic block popular Sizes (Length*width*thickness ) |
| 40*40*25 mm |
| 40*20*25 mm |
| 30*30*25 mm |
| 30*15*25 mm |
| 40*40*40 mm |
| 40*40*50 mm |
| 40*20*50 mm |
| 40*40*10 mm |
| 38*38*38 mm |
| 32*32*32 mm |
| 32*32*16 mm |
| More sizes and customized size acceptable. All alumina ceramic cube with tongues and grooves. |
Advantages
--- Tailor made engineered ceramics available
----Accept OEM & ODM wear engineered ceramics and project
--- Provide professional industrial wear consult and solution
---- Accept small and big quantity order
---- Delivery fast
Physical Perfomance
Performance Index | 92 series | 95series |
| Al2O3 (%) | ≥ 92 | ≥ 95 |
| Moh' s Hardness | 9 | 9 |
| Water Absorption Rate(%) | < 0.01 | < 0.01 |
| Flexural strength, 20C, Mpa | 275 | 290 |
| Bending strengh(Mpa) | 255 | 275 |
| Bulk density(g/cm 3 ) | ≥ 3.60 | ≥ 3.65 |
