Product Description
| Product Name | 99% Alumina Ceramic Big Size Tube for Furnace |
| Material | 99% Alumina |
| Size | φ80*φ70*1000mm |
| Forming Method | Slip Casting |
| Payment | T/T |
| Transport | Air Transportation;Sea Transportation |
| Delivery Time | Stock Products:3-7 days after receiving payment. Production Products:35-45 days after receiving payment. |
Alumina ceramic furnace tubes are widely used in high temperature tube furnaces, the operating temperature can reach 1600 ºC, and the conventional diameter is 60mm-120mm. The corundum furnace tube is an important ceramic part of the tube furnace. It is installed in the middle of the furnace. Both ends are covered with metal flanges for sealing. The material is put into the crucible and placed in the furnace tube.
-The porosity is 0,Good tightness,air tight
-High temperature resistance,1600ºC
-Stand wear and tear
-High hardness
-High strength
-Resistance to electric breakdown
| OD | 30 | 40 | 50 | 60 | 70 | 80 | 90 | 100 | 110 | 120 |
| ID | 25 | 30 | 40 | 50 | 60 | 70 | 80 | 90 | 100 | 110 |
| Lenght | 95AL/99AL/995AL ≤3000mm | |||||||||
| Material | Alumina | Zirconia | Recrystallization Silicon carbide | Silicon Nitride bonded Silicon Carbide | ||||
| Properties | Units | AL997 | AL995 | AL99 | AL95 | Zro2 | RSiC | NSiC |
| %Alumina | -- | 99.70% | 99.50% | 99.00% | 95% | -- | -- | -- |
| Color | -- | lvory | lvory | lvory | lvory&White | lvory White | black | gray |
| Permeability | -- | Gas-tight | Gas-tight | Gas-tight | Gas-tight | Gas-tight | -- | -- |
| Density | g/cm³ | 3.94 | 3.9 | 3.8 | 3.75 | 5.89 | 2.7 | 2.8 |
| Straightness | -- | 1‰ | 1‰ | 1‰ | 1‰ | 1‰ | 1‰ | 1‰ |
| Hardness | Mohs Scale | 9 | 9 | 9 | 8.8 | 8.5 | 9.5 | 9 |
| Water Absorption | -- | ≤0.2 | ≤0.2 | ≤0.2 | ≤0.2 | 0 | 0 | 0 |
| Flexural Strength (Typical 20ºC) | Mpa | 375 | 370 | 340 | 304 | 1200 | 90 | 180 |
| Compressive Strength (Typical 20ºC) | Mpa | 2300 | 2300 | 2210 | 1910 | 5700 | 600 | 650 |
| Coefficient of Thermal Expansion (25ºC to 800ºC) | 10-6/ºC | 7.6 | 7.6 | 7.6 | 7.6 | 10 | 4.7 | 5 |
| Dielectric Strength (5mm Thickness) | AC-kv/mm | 10 | 10 | 10 | 10 | -- | -- | -- |
| Dielectric Loss 25ºC@1MHz | -- | <0.0001 | <0.0001 | 0.0006 | 0.0004 | 0.001 | -- | -- |
| Dielectric Constant | 25ºC@1MHz | 9.8 | 9.7 | 9.5 | 9.2 | 29 | -- | -- |
| Volume Resistivity (20ºC) (300ºC) | Ω·cm³ | >1014 2*1012 | >1014 2*1012 | >1014 4*1011 | >1014 2*1011 | >1013 5*108 | -- | -- |
| Long-term operating temperature | ºC | 1700 | 1650 | 1600 | 1400 | 2200 | 1650 | 1450 |
| Thermal Conductivity (25ºC) | W/m·K | 35 | 35 | 34 | 20 | 3 | 23 | 15 |
Q1:Is it available to produce customized products?
A:We support custom-made alumina ceramic tubes as per different dimensions,designs, surface treatment
Q2.When can I get the price after sending the inquiry?
A:We regularly quote within 24 hours after we get your inquiry.lf you are in urgent need of getting the price, Please call us or tell us in your email so that we will proceed with your inquiry as a priority.
Q3.How long does the whole procedure being worked out?
A:After you place an order, the manufacturing time is about 25 working days.
Q4.How to ensure quality in your factory?
A:The strict quality-control will be done in the production line,including IQC,IPQC,QA,OQC, Also both CKP, AQL are regularly used in production.
Q5. Are you a factory or trading company?
A:We are a professional manufacturer. You are welcome to visit our factory and cooperate with us.
