Product Description
AlN substrate can be the best solution in electronics applications where strict conditions are required, such as power modules (MOSFET, IGBT), LED packages for cooling and protecting circuits, packages, and modules.
The specification of ceramic wafers and substrate
| Material | Aluminum nitride (AlN), alumina(al2o3), zirconia(ZrO2), silicon nitride(Si3N4), silicon carbide(SiC) |
| Color | Gray, black, white, pink, ivory, yellowish available |
| Dimensional capability | OD can be 400mm, Thickness can be range from 0.30mm to 30mm |
| Tolerance | OD can be ± 0.01mm, Thickness can be ± 0.005mm |
| Surface treatment: | natural surface, lapping, diamond-like polishing, metallization, glazed |
The main features of AlN ceramic wafers and substrate
1. High thermal conductivity (170 ~220) W/m.k, it's 5~8.5 times higher than that of alumina
2. Similar coefficient of thermal expansion to that of silicon (Si), it helps to achieve high reliability of Si chip
3. High insulation resistance and voltage resistance strength, but low dielectric constant and dielectric loss
4. High mechanical strength, it's up to 450MPa and very dense ceramic body free of porosity
5. It offers very high purity up to 99%, also it's free of toxicity and meets RoHS, REACH regulation
Related products for AlN ceramic wafer
Remark:
We produce a selection of ceramic wafers in different materials, customized designs, including alumina ceramic wafers, zirconia ceramic wafers, silicon nitride ceramic wafers, and silicon carbide wafers.
Why choose us?
1. 10+ Years of manufacturing experience in OEM, ODM and trusted & professional teams
2. Powerful R&D, prototyping & mass production capability to support trial order and high volume production
3. In-house comprehensive manufacturing types of equipment from raw materials to high precision machining
4. Rigorous quality control system and processes, including IQC, IPQC, QA, OQC in working instructions
5. Surpassing pre-sales, sales, and after-sales service, abide all orders every customer as the first priority
Production capability and our strength
Rigorous quality-control system
FAQs (Frequently Asked Questions)
Q1. Are you a factory or trading company?
A: We are a direct professional manufacturer for technical ceramics. You are welcome to visit our factory.
Q2: Do you send a sample to check?
A: Sure, the free sample with standard design in stock can be supplied, but freight collect.
Q3: When can I get the price?
A: We regularly quote within 24 hours after we get your inquiry. If you are in urgent need of getting the price.
Please call us or tell us in your email so that we will proceed with your inquiry as a priority.
Q4: Is it available to provide customized products?
A: We always support custom-made ceramic sheets as per different materials, dimensions, and designs.
Q5: What any other products do you manufacture?
A: Yes, we also produce metalized ceramics, ceramic tubes, zirconia ceramic parts, ceramic seals besides ceramic wafers
